Atari 600XL / 800XL Computer Cap Kit

This kit contains all parts necessary to replace the axial and radial electrolytic capacitors in the Atari 600XL or 800XL Home Computer.

Confirmed for revisions:
Rev A (PAL and probably NTSC)
Rev D
Chelco Rev 8A

Probably needs tailoring for:
Chelco Rev 3

If you have a different revision, please contact us beforehand to ensure the proper parts are included for your 600XL.

NTSC 600XL

Chelco Rev. 8A

C1	22uF	16v
C6	22uF	16v
C13	22uF	16v
C44	47uF	10v
C64	22uF	16v
C79	22uF	16v
C83	10uF	16v
C95	470uF	16v
C100	4.7uF	35v	NP
C101	10uF	16v
C102	4.7uF	35v	NP
C103	4.7uF	35v	NP
C115	10uF	16v

PAL / 600XL

Rev A

C1	22uF	16v
C6	22uF	16v
C13	22uF	16v
C44	47uF	10v
C64	22uF	16v
C83	10uF	16v
C95	470uF	16v
C100	4.7uF	35v	NP
C101	10uF	16v
C102	4.7uF	35v	NP
C103	4.7uF	35v	NP
C115	10uF	16v

800XL

C1	470uF	10v	(probably 16v - kits include 16v cap)
C2	22uF	16v
C3	22uF	16v
C10	22uF	16v
C19	4.7uF	35v	NP
C20	4.7uF	35v	NP
C22	4.7uF	35v	NP
C24	10uF	16v
C49	47uF	10v	(might be 25v on some but circuit is only 5v)
C50	10uF	16v
C79	22uF	16v
C98	10uF	16v

(Sourced directly from Console5)
