Atari 810 Floppy Disk Drive Cap Kit

This kit contains all parts necessary to replace the electrolytic capacitors in the Atari 810 floppy drive.

Large cap note: The original 4700uF caps have very wide lead spacing and 3 legs compared to most modern replacements. Some amount of lead forming will be required to match the original spacing. The original middle pin is only for support, replacements will be soldered to the wider 12mm spaced holes on the board.

810 Original

Rear Board CA014161
C142	47uF	16v
C143	10uF	16v
C146	4700uF	25v
C148	4700uF	25v
C149	4700uF	25v
C150	470uF	16v
C151	470uF	16v
C160	10uF	16v

Side Board CA014834
C132	4.7uF	35v

810M (MPI) / 810T (Tandon)

Analog PSU
C100	47uF	16v
C101	47uF	16v
C107	10uF	16v
C110	4700uF	25v
C112	4700uF	25v
C113	4700uF	35v
C116	470uF	16v
C117	470uF	16v

Side/Shield Board
C132	4.7uF	35v

Analog Board
C200	10uF	16v
C201	10uF	16v

(This is sourced directly from Console5)
